显示像素:176x220
显示像素:320x480
显示像素:480x272
显示像素:480x272
显示像素:1080(RGB)×1920
显示像素:800 x 3(RGB) x 480
显示像素:800 × 3(RGB) × 600
显示像素:1280(H)×800(V)(LVDS)
显示像素:800 × 3(RGB) × 600
型号 |
屏幕尺寸 |
分辨率 |
外型尺寸(mm) |
显示尺寸(mm) |
接口方式 |
工作温度℃ |
储存温度℃ |
工作电压(v) |
亮度(cd/m2) |
功耗(W) |
|---|---|---|---|---|---|---|---|---|---|---|
NHT020DN01(无铅) |
2.0 |
176*RGB*220 |
38.40*51.40*2.25 |
31.68*39.60 |
MCU/SPI |
-20~+70 |
-30~+80 |
2.6~3.3 |
220 |
0.2 |
NHT024DN01(无铅) |
2.4 |
240*RGB*320 |
42.72*60.26*2.30 |
36.72*48.96 |
SPI/MCU/RGB |
-20~+70 |
-30~+80 |
2.6~3.3 |
280 |
0.258 |
NH27011 |
2.7 |
960*RGB*240 |
39.10*67.50*2.40 |
33.06*58.80 |
RGB |
-20~+70 |
-30~+80 |
3.3/9.6 |
180 |
0.192 |
NH-28T2432-37P |
2.8 |
240*RGB*320 |
49.9*69.2*2.35 |
43.2*57.6 |
MCU |
-20~+70 |
-30~+80 |
2.8 |
180 |
0.206 |
NHT035DN01(无铅) |
3.5 |
320*RGB*480 |
54.66*82.94*2.25 |
48.96*73.44 |
SPI/MCU/RGB |
-20~+70 |
-30~+80 |
1.8/2.8 |
300 |
0.374 |
NHT035DN11(无铅) |
3.5 |
320*RGB*480 |
54.46*82.70*2.25 |
48.96*73.44 |
SPI/MCU/RGB |
-20~+70 |
-30~+80 |
3.3 |
300 |
0.374 |
NH035H1-51NV-A5 |
3.5 |
320*RGB*480 |
54.34*84.10*2.34 |
48.96*73.44 |
SPI/MCU/RGB |
-20~+70 |
-30~+80 |
1.8/2.8 |
200 |
0.396 |
NH035NC111 |
3.5 |
320*RGB*240 |
76.90*63.90*3.26 |
70.08*52.56 |
RGB |
-20~+70 |
-30~+80 |
3.3 |
250 |
0.43 |
NH035D7-54NI-A1 |
3.5 |
320*RGB*240 |
76.90*63.90*3.05 |
70.08*52.56 |
RGB |
-20~+70 |
-30~+80 |
3.3 |
250 |
0.43 |
NH4300HD4V05-RTP |
4.3 |
480*RGB*272 |
105.40*67.10*4.4 |
95.04*53.856 |
RGB |
-20~+70 |
-30~+80 |
3.3/21 |
450 |
0.453 |
NH4300HD4V05-CTP |
4.3 |
480*RGB*272 |
105.40*67.10*4.25 |
95.04*53.856 |
RGB |
-20~+70 |
-30~+80 |
3.3/21 |
450 |
0.453 |
NH-4300TWK-V05 |
4.3 |
480*RGB*272 |
105.42*67.07*2.90 |
95.04*53.86 |
RGB |
-20~+70 |
-30~+80 |
3.3/21 |
480 |
0.453 |
NH1TF-4306N106 |
4.3 |
480*RGB*272 |
105.40*67.10*2.9 |
95.04*53.86 |
RGB |
-20~+70 |
-30~+80 |
3.3 |
480 |
0.45 |
NH050-B2414 |
5.0 |
480*RGB*854 |
120.05*66.40*2.16 |
109.53*61.56 |
MIPI |
-20~+70 |
-30~+80 |
3.3 |
200 |
0.8 |
NH050-B2411-A |
5.0 |
480*RGB*854 |
120.05*66.40*2.16 |
109.53*61.56 |
MIPI |
-20~+70 |
-30~+80 |
1.8/3.3 |
300 |
0.8 |
NH050-B2411-A-CTP |
5.0 |
480*RGB*854 |
125.60*67.65*3.21 |
109.526*61.560 |
MIPI |
-20~+70 |
-30~+80 |
1.8/3.3 |
300 |
0.8 |
NHT050DL01-CTP |
5.0 |
480*RGB*272 |
120.70*75.80*4.7 |
110.88*62.832 |
RGB |
-20~+70 |
-30~+80 |
3.3/19.2 |
400 |
0.8 |
NHT050DL01-RTP |
5.0 |
480*RGB*272 |
120.70*75.80*4.3 |
110.88*62.832 |
RGB |
-20~+70 |
-30~+80 |
3.3/19.2 |
400 |
0.8 |
NH050PWV80480E40-RTP |
5.0 |
800*RGB*480 |
120.70*75.90*4.3 |
108.0*64.80 |
RGB |
-20~+70 |
-30~+80 |
3.3/19.2 |
400 |
0.8 |
NH050PWV80480E40-CTP |
5.0 |
800*RGB*480 |
120.70*75.90*4.7 |
108.0*64.80 |
RGB |
-20~+70 |
-30~+80 |
3.3/19.2 |
400 |
0.8 |
NH050PWV80480E40-CTP |
5.0 |
800*RGB*480 |
120.70*75.90*4.7 |
108.0*64.80 |
RGB |
-20~+70 |
-30~+80 |
3.3/19.2 |
400 |
0.8 |
NH-50005TK-V05 |
5.0 |
480*RGB*272 |
120.70*75.80*3.20 |
110.880*62.832 |
RGB |
-20~+70 |
-30~+80 |
3.3 |
480 |
0.8 |
NH050NA-08C |
5.0 |
640*RGB*480 |
117.65*88.43*5.70 |
101.568*76.176 |
RGB |
-20~+70 |
-30~+80 |
3.3 |
250 |
0.960 |
NH056TN53V.1 |
5.6 |
640*RGB*480 |
126.5*100.0*5.7 |
112.896*84.672 |
RGB |
-20~+70 |
-30~+80 |
3.3/5.0 |
350 |
2.56 |
NH056TN52 v.1 |
5.6 |
640*RGB*480 |
126.50*100.00*5.70 |
112.896*84.672 |
RGB |
-20~+70 |
-30~+80 |
3.3/5.0 |
200 |
2.33 |
NH060G3-40TT-A2 |
6.0 |
800*RGB*480 |
145.50*87.80*4.49 |
133.20*73.80 |
RGB |
-20~+70 |
-30~+80 |
3.3 |
200 |
1.19 |
NH062IDW1-A |
6.2 |
800*RGB*480 |
155.2*88.2*5.0 |
137.520*77.232 |
RGB |
-20~+70 |
-30~+80 |
3.3 |
400 |
1.58 |
NH1TF‐6208R002 |
6.2 |
800*RGB*480 |
155.20*88.20*6.40 |
137.52*77.23 |
RGB |
-20~+70 |
-30~+80 |
3.3 |
600 |
1.58 |
NH070BIH4090-21 |
7.0 |
1024*RGB*600 |
164.9*100*2.8 |
154.215*85.92 |
LVDS |
-20~+60 |
-30~+70 |
3.3 |
250 |
1.313 |
NH-Q302-36C |
7.0 |
800*RGB*480 |
165.00*100.00*5.70 |
154.21*85.92 |
RGB |
-20~+60 |
-30~+70 |
3.3 |
900 |
1.74 |
NH070TN02-27L-CTP |
7.0 |
800*RGB*480 |
182.07*117.60*8.30 |
154.21*85.92 |
RGB |
-20~+70 |
-30~+80 |
3.3/9.6 |
400 |
1.74 |
KD070C-4-CTP-002 |
7.0 |
800*RGB*480 |
182.07*117.60*8.30 |
154.21*85.92 |
RGB |
-20~+70 |
-30~+80 |
3.3 |
400 |
1.74 |
NH070TN83 V.1 |
7.0 |
800*3(RGB)*480 |
165.0*104.0*5.5 |
152.40*91.44 |
RGB |
-20~+70 |
-30~+80 |
3.3/5.0 |
300 |
0.825 |
NH07057IBHP5F27S11 |
7.0 |
800*3(RGB)*480 |
164.9*100.0*5.7 |
154.08*85.92 |
RGB |
-10~+60 |
-20~+70 |
3.3 |
450 |
0.226 |
NH070JDHG30 |
7.0 |
1280*RGB*800 |
161.00*107.00*3.35 |
149.76*93.60 |
LVDS |
-20~+70 |
-30~+80 |
3.3/11.0 |
400 |
1.5 |
NH080SDH01-00 |
8.0 |
800*RGB*600 |
183.03*141.03*5.60 |
162.0*121.5 |
RGB |
-20~+70 |
-30~+80 |
3.3 |
250 |
1.728 |
NH084VC03 |
8.4 |
640*RGB*480 |
199.5*149.0*11.5 |
170.9*128.2 |
RGB |
0~+50 |
-20~+60 |
3.3 |
350 |
5.4 |
NH104SN03 V1 |
10.4 |
800*RGB*600 |
228.4*175.4*6.2 |
211.2*158.4 |
RGB |
-10~+60 |
-20~+70 |
3.3/5.0 |
300 |
1.728 |
NH104X1-L03 |
10.4 |
1024*RGB*768 |
238.6*175.8*6.61 |
210.432*157.824 |
RGB |
-20~+70 |
-20~+70 |
3.3 |
350 |
5.1 |
NH104TN14 |
10.4 |
800*3(RGB)*600 |
228.40*175.40*5.9 |
211.20*158.40 |
RGB |
-10~+50 |
-20~+60 |
3.3 |
400 |
2.304 |
NH116LF1L01-RJ |
11.6 |
1920*RGB*1080 |
270.62*159.76*2.59 |
256.32*144.18 |
RGB |
-10~+60 |
-20~+70 |
3.3 |
250 |
3.42 |
NH121SA01 |
12.1 |
800*RGB*600 |
260.5*203.0*8.8 |
246.0*184.5 |
LVDS |
-30~+80 |
-30~+80 |
3.3 |
450 |
3.1 |
NH121SDS01 |
12.1 |
800*RGB*600 |
279*209*9 |
246.0*184.5 |
LVDS |
-30~+80 |
-30~+80 |
3.3 |
450 |
3.1 |
NH156BGE-L01 |
15.6 |
1366*RGB*768 |
363.8*215.9*16.85 |
344.232*193.536 |
LVDS |
0~+60 |
-20~+60 |
5.0/12.0 |
300 |
10.8 |
NH156LF1L02 |
15.6 |
1920*RGB*1080 |
359.50*223.75*3.30 |
344.16*193.50 |
RGB |
-10~+60 |
-35~+70 |
3.3/12 |
220 |
0.561 |
NH173HTN01.1 |
17.3 |
1920*RGB*1080 |
398.6*233.3*6.0 |
381.89*214.81 |
RGB |
0~+50 |
-20~+60 |
3.3 |
300 |
9.0 |
NH185WHB-N20 |
18.5 |
1366*RGB*768 |
422.2*244.1*6.4 |
409.8*230.4 |
LVDS |
0~+50 |
-20~+60 |
5.0 |
1000 |
2.5 |
NH215HJJ-P02(900亮度) |
21.5 |
1920*RGB*1080 |
495.6*292.2*11.0 |
476.064*267.768 |
LVDS |
0~+50 |
-20~+60 |
5.0/48 |
900 |
28.6 |
M215HJJ-P02(900亮度)(L) |
21.5 |
1920*RGB*1080 |
495.6*292.2*16.0 |
476.064*267.768 |
LVDS |
0~+50 |
-20~+60 |
5/48 |
900 |
28.6 |
M215HJJ-P02(900亮度)(R) |
21.5 |
1920*RGB*1080 |
495.6*292.2*16.0 |
476.064*267.768 |
LVDS |
0~+50 |
-20~+60 |
5/48 |
900 |
28.6 |
NH215DT01 V2.0(L) |
21.5 |
1920*RGB*1080 |
495.6*292.2*16.0 |
476.064*267.768 |
LVDS |
0~+50 |
-20~+60 |
5/48 |
250 |
15.2 |
NH215DT01 V2.0(R) |
21.5 |
1920*RGB*1080 |
495.6*292.2*16.0 |
476.064*267.768 |
LVDS |
0~+50 |
-20~+60 |
5/48 |
250 |
15.2 |
NH215HVN01.1 |
21.5 |
1920*RGB*1080 |
495.6*292.2*10.6 |
476.64*268.11 |
LVDS |
0~+50 |
-20~+60 |
5/48 |
250 |
15.2 |
NH236HJJ-L31 |
23.6 |
1920*RGB*1080 |
554.80*320.50*8.30 |
521.28*293.22 |
LVDS |
0~+50 |
-20~+60 |
5 |
250 |
18.35 |
NH240WU8 |
24 |
1920*RGB*1200 |
546.4*352.0*11.7 |
518.4*324.0 |
LVDS |
0~+40 |
-20~+60 |
10 |
300 |
15.55 |
NH320FHB-N00 |
32 |
1920*RGB*1080 |
708.4*405.4*1.0 |
698.40*392.85 |
LVDS |
0~+50 |
-20~+60 |
12 |
500 |
4.0 |
NH320EUJ |
32 |
1920*RGB*1080 |
714.0*411.0*1.4 |
698.40*392.85 |
LVDS |
0~+50 |
-20~+60 |
12 |
450 |
15.55 |
